Rock Wool Insulation Board – Class A1 Fireproof Thermal and Acoustic Insulation for Building

Name: Rock Wool Insulation Board Class A1 Fireproof Thermal and Acoustic Insulation for Building
Brand: SUNWOOL
Price: 1.0 USD

Quality Rock Wool Insulation Board – Class A1 Fireproof Thermal and Acoustic Insulation for Building for sale

Package : plastic bag

Model Number : 40-200KG/M3

Refractoriness : 750C

Price : 1.0usd - 5.0usd

Blanket density : 50-120kg/m3

Certification : ISO CE

Board density : 40-200kg/m3

MOQ : 100 pcs

Delivery Time : 7 days

Type : board,pipe blanket

Payment Terms : L/C,D/P,T/T,Western Union

Pipe density : 80-150kg/m3

Place of Origin : CHINA

Supply Ability : 1000 tons/month

Size : customizable

Brand Name : SUNWOOL

Packaging Details : Plastic Bag

Contact Now

Rock Wool Insulation Board – Class A1 Fireproof Thermal and Acoustic Insulation for Building

Our Rock Wool Insulation Board is a high-performance thermal and acoustic insulation solution manufactured from natural volcanic rock such as basalt and dolomite. The raw materials are melted at approximately 1500°C and centrifuged into fine fibers, then formed into rigid boards through a controlled process involving pendulum laying, pleating, pressurization, and curing.

With density options ranging from 60kg/m³ to 200kg/m³, our rock wool boards deliver exceptional fire resistance, thermal insulation, moisture repellency, and acoustic performance, making them a reliable choice for demanding building, industrial, and marine applications.

Each board is produced under strict quality control protocols, ensuring consistent density, dimensional accuracy, and reliable performance. The material is hydrophobic treated (≥98% water repellence), non-combustible (Class A1), and contains no asbestos or CFCs, providing a safe, durable, and environmentally responsible insulation solution for both indoor and outdoor use.

Technical Specifications

Product performance	Unit	LDS 60-200	Standard
Apparent Density	kg/m3	140 \| 160 \| 180	GB/T5480
Compression strength (10% deformation)	kPa	≥40 \| ≥50 \| ≥60	GB/T13480
Tensile strength (perpendicular to surface)	kPa	≥7.5 \| ≥10 \| ≥15	JG149-2003
Thermal conductivity (25℃)	w/(m•K)	≤0.040 \| ≤0.040 \| ≤0.040	GB/T10295
Fire resistant	--	Non-combustible grade A	GB/T8624
Water repellence	%	≥98 \| ≥98 \| ≥98	GB/T10299
Acid index	--	≥1.8 \| ≥1.8 \| ≥1.8	GB/T5480
Moisture absorption	%	≤1.0 \| ≤1.0 \| ≤1.0	GB/T5480
Water Absorption (partial immersion 24h)	kg/m2	≤0.5 \| ≤0.5 \| ≤0.5	GB/T25975-2010
Water Absorption (partial immersion 28d)	kg/m2	≤2.0 \| ≤2.0 \| ≤2.0	GB/T25975-2010
Noise Reduction Coefficient (NRC)	---	≥0.6 \| ≥0.6 \| ≥0.6	GB/T18696
Dimension Stability	%	≤1.0 \| ≤1.0 \| ≤1.0	GB/T8811
Thickness Tolerance	mm	±3 \| ±3 \| ±3	GB/T5480
Squareness	mm/m	≤5 \| ≤5 \| ≤5	GB/T5480
Flatness	mm	≤6 \| ≤6 \| ≤6	GB/T25975-2010
Melting Point	℃	＞1000

Why Choose Our Products?

Superior Fire Resistance - Class A1 non-combustible material with a melting point exceeding 1000°C. Provides critical fire protection for buildings, industrial facilities, and high-risk environments where fire safety is paramount.
Excellent Thermal Insulation - Low thermal conductivity (≤0.040 W/m*K at 25°C) ensures effective heat retention in winter and heat reflection in summer, significantly reducing energy consumption and operational costs.
Outstanding Acoustic Performance - Noise Reduction Coefficient (NRC) ≥0.6 effectively absorbs sound and reduces noise transmission, making it ideal for soundproofing in offices, studios, theaters, and industrial settings.
Environmentally Safe - Made from natural volcanic rock, free from asbestos and CFCs, with no fiber dust or harmful emissions, ensuring a safe working environment for installers and building occupants.

Primary Applications

Building Insulation - Thermal and acoustic insulation for roofs, walls, curtain walls, partition systems, pre-fabricated houses, and external cladding systems in residential, commercial, and public buildings.
Fire Protection - Fire barriers, fire-rated doors, structural fireproofing, industrial furnace lining, and passive fire protection systems requiring Class A1 non-combustible materials.
Marine and Transportation - Thermal and acoustic insulation for ships, offshore platforms, railway carriages, and automotive heat shielding applications where fire safety and moisture resistance are essential.

Frequently Asked Questions (FAQ)

Q1: What is the maximum service temperature for this rock wool board?

A: Our rock wool insulation board has a melting point exceeding 1000°C and can withstand continuous service temperatures up to 650°C. For higher temperature applications, please consult our technical team for specific recommendations.

Q2: Is this product suitable for outdoor applications?

A: Yes. Our rock wool board features advanced hydrophobic treatment with ≥98% water repellence, making it suitable for outdoor use. For extended outdoor exposure, we recommend adding a protective cladding or weatherproof finishing to ensure long-term performance.

Q3: How do I select the correct density for my project?

A: Density selection depends on your specific mechanical strength requirements and operating conditions. 60-100kg/m³ is suitable for general building insulation and acoustic applications. 120-150kg/m³ offers balanced performance for most industrial and construction applications. 160-200kg/m³ provides maximum compression and tensile strength for high-load or demanding industrial environments.
